LED High Bay



Vapor Tight Linear

High Bay

VESPA

(20W-120W)

Product Description:

The VESPA Series features a non-corrosive polycarbonate lens (PC) with stainless steel hasps and clips. This luminaire has a life span of over 100,000 calculated hours and uses hermatic sealing. The fixture provides a high efficiency frosted diffuser with advanced optical design to generate uniform light distribution with glare-free lumination. The VESPA can be mounted in 3 different ways and is applicable for garages, warehouses, stations, tunnels, etc.

FEATURES:

Application:

LED Source:

Warranty:

Long Life:

CRI:

Working Temp:

IP Rating:

Lab Tested:

Solid State:

Instant-On:

Qualifications:

LED Vapor Tight Linear High Bay

Philips Lumileds / Cree / Osram

5 years

100,000 +calculated hours at L70 standards

83 or 90

-4°F to 122°F

IP 66

National listing lab test in accordance with IES standards

High-shock and High-Vibration Resistance

Instant-On and Instant Re-strike

ETL certified

Fixture Model
Certification
Total Lumens
85ºx135º / 50K
Efficacy
(lm)
Dimensions
(Inch)
Weight
(lbs)
Beam
Angle
VESPA-20W
VESPA-20W
VESPA-24W
VESPA-40W
VESPA-60W
VESPA-80W
VESPA-120W
ETL
ETL
ETL
ETL
ETL
ETL
ETL
2,100 lm
2,100 lm
2,400 lm
4,203.8 lm
6,609.9 lm
8,422.1 lm
11,406.7 lm
> 105
> 105
> 100
> 105
> 110
> 105
> 95
24 x 5 x 4
48 x 5 x 4
48 x 5 x 4
48 x 5 x 4
48 x 5 x 4
51 x 6 x 4
51 x 6 x 4
2.13
4.18
4.18
4.31
4.4
5.5
5.76
120°
120°
120°
120°
120°
120°
120°

Dimensions:

VESPA

High Bay Series

General Info

EXPECTED LIFE:

100,000 + calculated hours at L70 standards

CRI:

83 or 90 available

COLOR TEMPERATURE:

3000K, 4000K, 5000K, 6000K

HOUSING:

Cold rolled steel housing, Aluminum

heatsink

LENS:

Polycarbonate

LED CHIPS:

Epistar 2835

BEAM ANGLES:

120°

WATTAGES:

20W, 24W, 40W, 60W, 80W, 120W

INPUT LINE VOLTAGES:

120-277V, 347V (optional)



INPUT LINE FREQUENCY:

50-60 Hz



POWER FACTOR:

> 0.90



DIMMABLE:

0-10V (optional)



THD:

< 13%

-4°F to 122°F

Grey (Standard)

For other color options (MOQ 500 units)  please contact our sales team for details

MOTION SENSOR:

MS1 (ON/OFF) or MS2 (DIM)

EMERGENCY BATTERY BACKUP:

EM

DIMMING (0-10V):

0-10V

DIMMING (DALI):

DALI

347V TRANSFORMER:

347V

480V TRANSFORMER:

480V

MOUNTING OPTIONS:

Surface (Direct)

V-Hook/Chain (Hanging/Suspended)

Single Aircraft Cable (Hanging/Suspended)

Double Aircraft Cable (Hanging/Suspended)

5 Year Warranty (fixture)

2 Year Warranty (emergency battery)

ETL listed

OPTICS
MATERIALS
PERFORMANCE
OPERATING TEMP.
ELECTRICAL
FINISH
LISTING
WARRANTY
ACCESSORIES

PHOTOMETRICS

VESPA 40W/
4000K
VESPA 120W/
4000K
