LED Sports Flood
SPARTAN-G2
(400W-1250W)
Product Description:
The SPARTAN-G2 Series delivers one of the largest lumen output in a sleek and compact fixture. This luminaire is designed for applications such as sporting arenas, gymnasiums, airports, construction sites, etc. The luminaire has a calculated life span of over 100,000 hours.
FEATURES:
Application:
LED Source:
Warranty:
Long Life:
CRI:
Working Temp:
IP Rating:
Lab Tested:
Solid State:
Instant-On:
Qualifications:
LED Sports Flood Light
Lumileds Luxeon 5050/ Cree / Osram
5 years
100,000 +calculated hours, 12 hrs per day for approximately 10 years
>70
-40F to 113F
IP 65
National listing lab test in accordance with IES standards
High-shock and High-Vibration Resistance
Instant-On and Instant Re-strike
ETL listed
Fixture Model
EPA
Total Lumens
Efficacy
(lm)
Dimensions
(Inch)
Weight*
(lbs)
Beam
Angles**
SPARTAN-G2-400W
SPARTAN-G2-600W
SPARTAN-G2-800W
SPARTAN-G2-1000W
SPARTAN-G2-1250W
1.37 (ft2)
1.95 (ft2)
2.38 (ft2)
2.94 (ft2)
2.94 (ft2)
61,600 lm
89,600 lm
123,200 lm
154,000 lm
168,750 lm
> 154
> 149.3
> 154
> 154
> 135
20.9 x 20.9 x 14.3
20.9 x 20.9 x 14.3
25.3 x 22.2 x 17.9
25.3 x 22.2 x 17.9
25.3 x 22.2 x 17.9
20.9
27.1
33.4
38.5
38.5
12°, 20°, 40°, 60°
12°, 20°, 40°, 60°
12°, 20°, 40°, 60°
12°, 20°, 40°, 60°
12°, 20°, 40°, 60°
* Total weight does NOT include Driver Box/Shield
Dimensions:
SPARTAN-G2-400W
SPARTAN-G2-800W
SPARTAN-G2-600W
SPARTAN-G2-1000W/1250W
SPARTAN-G2
Flood Light Series
General Info
EXPECTED LIFE:
100,000 + calculated hours; 12 hours per
day for 10 years
CRI:
>70
COLOR TEMPERATURE:
3000K, 4000K, 5000K, 5700K
HOUSING:
Rugged, corrosion resistant die-cast aluminum
LENS:
Tempered glass
LED CHIPS:
Lumileds Luxeon 5050 (default),
Cree XPG3/Osram Square available)
DRIVER:
Meanwell / Inventronics
BEAM ANGLES:
12°, 20°, 40°, 60°
WATTAGES:
400W, 600W, 800W, 1000W, 1250W
INPUT LINE VOLTAGES:
100-305V
INPUT LINE FREQUENCY:
50-60 Hz
POWER FACTOR:
0.90
DIMMABLE:
0-10V, DALI ( both optional)
-40°F to 122°F
Protective UV stabilized powder coated
finish
Black (RAL #9023)
White (RAL #9016)
Grey (RAL #9006)
For other colors options, please contact our sales team for details
DIMMING:
DM
AIMMING LASER:
AL
BULLSEYE HOOD:
BH
5 Year Warranty
ETL listed
OPTICS
MATERIALS
PERFORMANCE
ELECTRICAL
OPERATING TEMP.
FINISH
ACCESSORIES
LISTING
WARRANTY
GALLERY
External Driver
Bullseye Hood
Slipfitter Mounting
