LED High Bay
UFO-G4
(70W-300W)
Product Description:
The UFO-G4 Series utilizes a unique housing mold that gives the
fixture a distinct look while still keeping an overall traditional feel. The UFO-G4 is a strong fixture, offering up to 190 lm/W, is IP 66 rated, premium grade aluminum die cast housing and stainless steel hardware and is also available with motion sensor and emergency battery options.This fixture is ideal for warehouses, logistic centers, production workshops, storage facilities, and commercial spaces.
FEATURES:
Application:
LED Source:
Warranty:
Long Life:
CRI:
Working Temp:
IP Rating:
Lab Tested:
Solid State:
Instant-On:
Qualifications:
LED High Bay
Philips Lumileds Luxeon 3030
5 years
100,000 +calculated hours at L70 standards
70/80
-40°F to 122°F
IP 65 (IP67 available)
National listing lab test in accordance with IES standards
High-shock and High-Vibration Resistance
Instant-On and Instant Re-strike
ETL certified
Fixture Model
Total Lumens
Efficacy
(lm)
Dimensions
(Inch)
Weight
(lbs)
Beam
Angle
UFO-70W-G4
UFO-90W-G4
UFO-120W-G4
UFO-150W-G4
UFO-200W-G4
UFO-250W-G4
UFO--300W-G4
14,250 lm
18,620 lm
23,800 lm
28,900 lm
39,050 lm
46,670 lm
59,050 lm
190 lm/W
206.8 lm/W
198.3 lm/W
192.6 lm/W
195.3 lm/W
186.7 lm/W
196.8 lm/W
11.4" x 5.19"
11.4" x 5.19"
13.4" x 5.27"
13.4" x 5.27"
15.2" x 5.51"
15.2" x 5.51"
15.2" x 6.69"
3.63
3.63
4.62
4.62
6.38
6.38
9.9
90°/120°
90°/120°
90°/120°
90°/120°
90°/120°
90°/120°
90°/120°
Dimensions:
UFO-70W-90W-G4
UFO-120W-200W-G4
UFO-200W-250W-G4
UFO-300W-G4
UFO-G4
High Bay Series
General Info
EXPECTED LIFE:
100,000 + calculated hours at L70 standards
CRI:
>70/80
COLOR TEMPERATURE:
2700K, 3000K, 4000K, 5000K, 5700K, 6500K
HOUSING:
Rugged, corrosion resistant die-cast aluminum
LENS:
PMMA/PC
LED CHIPS:
Osram 3030
DRIVER:
Meanwell HLG, Inventronics available
BEAM ANGLES:
90°, 120°
WATTAGES:
70W, 90W, 120W, 150W, 200W, 250W, 300W
INPUT LINE VOLTAGES:
90-305V, 347-480 VAC (optional)
INPUT LINE FREQUENCY:
50-60 Hz
POWER FACTOR:
>0.95
DIMMABLE:
0-10V (optional)
THD:
< 20%
-40°F to 122°F
Protective UV stabilized powder coated
finish
Black (RAL #9011)
White (RAL #9016),
Grey (RAL #9006 or 7043)
Bronze (RAL #8019 or 8028)
* (Other colors available with RAL #, at extra cost, contact our sales team for details)
GLARE SHIELD:
GS
PHOTOCELL:
PC
EMERGENCY BATTERY BACKUP:
EM
MOTION SENSOR:
MS
WIRE GUARD:
WG
ALUMINUM REFLECTOR:
AL
DIMMING:
DM (0-10V Dimming)
UP-LIGHT LED STRIP:
UL
MOUNTING OPTIONS:
Hanging Ring, Pendant, Wall, 3 Chain
EXTENDED CORD WITH IP65 CONNECTOR + LENGTH:
IP65CC-Length (*Standard length is ~1ft)
IP67 RATING OPTION:
IP67
5 Year Warranty (fixture)
2 Year Warranty (emergency battery)
ETL
OPTICS
MATERIALS
PERFORMANCE
ELECTRICAL
FINISH
ACCESSORIES
LISTING
WARRANTY
OPERATING TEMP.
PHOTOMETRICS
UFO-90W-G4W/
90°x90°
UFO-250W-G4/
120°x120°
GALLERY
ACCESSORIES
UFO with Up-Light LED Strips
